IM C6010

IM C6010

A3 colour multifunction printer
– Copy, print, scan, optional fax
– Prints up to 60 ppm
– Top environmental performance
– Robust security

Category:

The IM C6010 is an intelligent MFP providing features to meet new digitally-enabled workplace demands, security and compliance challenges, as well as an increased business focus on environmental sustainability.

  • Supports integrated digital workflow processes
  • Latest security features
  • Stay up to date with RICOH Always Current Technology
  • Save costs by reduced energy consumption
  • Outer mainframe uses 50% post-consumer recycled materials

The IM C6010 is equipped with the latest generation 10.1” Smart Operation Panel that provides improved responsiveness with capacitive touch panel technology. It also comes with more memory and is powered by an updated Android OS 10 with enhanced security features.

The MFP also supports a range of optional accessories, including paper input and finishing options, that allow customers to produce quick, professional results.

Specification



  • Configuration
    Functions Copy, print, scan, optional fax
    Colour Yes
    HDD 256 GB SSD
    Memory - standard 8 GB—4 GB mainframe + 4 GB Smart Operation Panel
    Operation panel 10.1" Smart Operation Panel
  • Physical dimensions
    Physical dimensions (WxDxH)—mainframe 587 x 701 x 963 mm
    Weight—mainframe 100.8 kg
  • Media Handling
    Standard input capacity (sheets) 1,200
    Maximum input capacity (sheets) 4,700
    Standard output capacity (sheets) 500
    250—B4 or larger
    Maximum output capacity (sheets) 3,625
    Paper input configuration - standard 2 x 550-sheet paper trays, 100-sheet bypass tray, 220-sheet SPDF, duplex unit
    Paper output configuration - standard 500-sheet face-down internal output tray
    Supported media

    Tray 1
    Plain paper (paper type not displayed), recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, high gloss coated paper, coated paper

    Tray 2
    Plain paper (paper type not displayed), recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, high gloss coated paper, coated paper, envelope

    Optional trays
    Plain paper (paper type not displayed), recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, high-gloss coated paper, envelope, coated paper

    Bypass tray
    Plain paper (paper type not displayed), recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, high-gloss coated paper, envelope, coated paper, label paper

    Maximum paper size SRA3
    Media weight (g/m2) 52–300
  • Connectivity
    Interfaces - standard

    Mainframe
    10Base-T/100Base-Tx (Ethernet)
    1000Base-T (Gigabit Ethernet)
    USB Host Type A—2 ports
    USB Type B—1 port

    Smart Operation Panel
    Bluetooth 5.21
    USB Host Type A—USB Flash memory
    USB Host Type A—optional 1 port for USB keyboard

    1
    —Cannot be used for printing

    Interfaces - optional IEEE 802.11 a/b/g/n/ac Interface Unit Type M52
    Device Server Option Type M52 (additional Ethernet/Gigabit Ethernet port)
    Network protocols - standard TCP/IP (IPv4, IPv6)
  • Copy features
    Copy speed 60 cpm
    First copy time 2.9 seconds—black and white
    4.2 seconds—colour
    Copy resolution 100, 200, 300, 400, 600 dpi—scanning
    1,200 x 1,200 dpi (maximum)—printing
    Zoom range 25%–400% in 1% steps
    Enlargement ratios 115%, 122%, 141%, 200%, 400%
    Reduction ratios 93%, 87%, 82%, 71%, 61%, 50%, 25%
    Duplex copy Simplex to duplex, duplex to duplex—with SPDF, book to duplex, front and back to duplex
    Book copy Booklet, magazine, layout and booklet
  • Print features
    Print speed colour 60 ppm
    Print speed black and white 60 ppm
    First print time 2.4 seconds black and white, 3.8 seconds colour
    Print resolution 1,200 x 1,200 dpi
    Page description languages (PDLs) Standard PCL 5c, PCL 6,PostScript 3 emulation, PDF Direct emulation Optional Genuine Adobe PostScript 3, PDF Direct from Adobe
    Printer drivers Standard PCL 5c, PCL 6,PostScript 3 emulation Optional Genuine Adobe PostScript 3
    Duplex printing Standard
    Mobile printing Yes
  • Scan feautures
    Scan speed Via SPDF
    150 ppm—simplex, 200 x 200 dpi
    120 ppm—simplex, 300 x 300 dpi
    300 ppm—duplex, 200 x 200 dpi
    220 ppm—duplex, 300 x 300 dpi
    Scan methods

    Scan to USB, Scan to email, Scan to folder, Scan to URL, Scan to MSB, Scan to FTP, Scan to PDF/A, Scan to digitally signed PDF, Scan to searchable PDF

    Note: Optional OCR unit is required to support scanning to a searchable PDF.

    Colour scanning Standard
    Scan resolution 100 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi, 1,200 dpi
    Note:1,200 dpi scanning is supported only with A5 or smaller paper size.
    Scan to file types Single- and multi-page TIFF
    Single-page JPEG
    Single- and multi-page PDF, PDF/A
    Single- and multi-page high-compression PDF
    Scan to email

    Protocols
    SMTP gateway, TCP/IP, POP, IMAP 4

    Authentication

    SMTP authentication, POP before SMTP authentication

    Scan resolution
    100 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi

    Scan to email file types
    Single-page
    TIFF, JPEG, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF

    Multi-page
    TIFF, PDF (default), PDF/A, high-compression PDF, encrypted PDF, searchable PDF

    Note: Optional OCR unit is required to support scanning to a searchable PDF.

    Scan to folder

    Protocols
    SMB, FTP

    Resolution
    100 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi

    Search for client folders
    SMB—browsing directly to the designated folder
    FTP—by folder name

    Scan to folder file types
    Single-page
    TIFF, JPEG, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF

    Multi-page
    TIFF, PDF (default), PDF/A, high-compression PDF, encrypted PDF, searchable PDF

    Note:Optional OCR unit is required to support scanning to a searchable PDF.

    TWAIN scanning Scan mode
    Standard, Photo, OCR, Filing
    Note: Optional OCR unit required for OCR scanning.

    Scan resolution
    100–1,200 dpi
    Note: 1,200 dpi scanning is supported only with A5 or smaller paper size.
  • Fax features
    Fax types G3 fax, Internet fax (T.37), IP fax (T.38), LAN-Fax, Paperless fax, Direct SMTP fax
    Fax circuit PSTN, PBX
    Fax compatibilty ITU-T (CCITT), G3—maximum 3 lines
    Fax modem speed 2,400 bps–33.6 Kbps—G3, standard with automatic shift down
    Fax compression methods MH, MR, MMR, JBIG
    Fax resolution Standard mode 200 x 100 dpi—8 x 3.85 lines/mm Detail mode 200 x 200 dpi—8 x 7.7 lines/mm Super Fine mode 400 x 400 dpi—8 x 15.4 lines/mm 400 x 400 dpi—16 x 15.4 lines/mm Note: Super Fine mode is supported with the optional SAF memory.
    G3 fax transmission speed 3 seconds approximately—JBIG, ITU-T No. 1 chart, TTI off, memory transmission 3 seconds approximately—MMR, ITU-T No. 1 chart, TTI off, memory transmission
    Fax SAF memory capacity Standard 4 MB—approximately 320 pages With optional SAF memory 60 MB—approximately 4,800 pages
    Fax memory backup 1 hour
    Quick dials 2,000 numbers
  • Security features
    Encryption SSD, PDF, Secure print, WEP, WPA Authentication password Encryption of data sent via Scan to email and Fax forwarding (S/MIME)
    Authentication 802.1x wired authentication Administrator authentication IEEE 802.11i security (WPA2) IPv6 Quota setting User authentication—Windows and LDAP via Kerberos, basic, user code WiFi Protected Setup (WPS) support
  • Supported operating environments
    Windows PCL 5c, PCL 6, and PostScript 3 Windows 8.1 Windows 10 Windows Server 2012 Windows Server 2012 R2 Windows Server 2016 Windows Server 2019 Windows Server 2022
    Macintosh MacOS v10.15 or later—PostScript 3 only
    Unix PCL 5c, PostScript 3 Sun Solaris, HP-UX, SCO OpenServer, Red Hat Linux, IBM AIX
    SAP PCL 5c R/3, S/4
  • Software and solutions
    Standard @Remote Embedded Web Image Monitor
    Optional Streamline NX V3 GlobalScan NX Enhanced Locked Print NX Card Authentication Package
    Mobile apps RICOH Smart Device Connector
  • Environmental features
    Power source  220–240 V, 50/60 Hz—Asia Pacific
    110 V, 60 Hz—Taiwan
     Power consumption  1,850 W or less—maximum power, Asia Pacific
    1,584 W or less—maximum power, Taiwan
    763.3 W—operating power, black and white
    871.2 W—operating power, colour
    40.1 W—Ready Mode
    0.32 W—Energy Saver Mode (Sleep Mode)
     Typical Electricity Consumption (TEC)  0.67 kWh
     Warm-up time

    23 seconds

     Recovery time  From Energy Saver Mode
    7.4 seconds
     Green labels  The Thai Green Label Scheme
     Other environmental features  Eco-friendly indicator, Energy Saver Timer, System Reset Timer

Features

An intelligent device that supports your business

You want technology that offers mobility, productivity and security whether employees are in the office or working remote. The RICOH IM C6010 Color Laser Multifunction Printer (MFP) exceeds expectations with the added benefits of high-speed output, advanced finishing options, automatic upgrades, cloud integration and a tablet-like control panel. It’s a robust, eco-friendly, intelligent device designed for the way business is done today.

Optimize workflows to stay ahead

You rely on the latest technologies to deliver work that is fresh and relevant. Empower your teams with the RICOH IM C6010 so they can seamlessly connect to the cloud, stay secured and work where they need to. Our series of intelligent devices comes standard with the RICOH Always Current Technology platform — giving your business the agility to scale and add new apps and upgrades as needed.

Experience a familiar and intuitive interface

Easily unlock the system’s full potential with its highly-interactive 10.1″ Smart Operation Panel and intuitive interface. Swipe between tasks with ease. Integrate with cloud-based platforms including SharePoint®, Google Drive™ and Dropbox™. Use Full View mode to access copier and scan settings. Add widgets to create shortcuts and personalize the user experience.

Collaborate digitally to get more done

Double your efficiency with a 220-sheet Single Pass Document Feeder that scans double-sided files in one pass. Scan files at up to 300 images per minute and meet tight timelines. Easily digitize smaller documents in non-traditional formats. Rely on the RICOH IM C6010 to handle your hard copy document workflow and to send and store your digital information.

Configure the system to meet your precise needs

Achieve color-rich output at up to 60 ppm and 1200 x 1200 dpi. An optional Fiery® Color Controller E-26C yields brand-compliant color reproductions. Stapleless binding and saddle-stitch finishing options allow you to do more internally and reduce outsourcing costs. And an optional internal Multi-Folding Unit is perfect for creating newsletters, trifolds and more.
